3-4 to 1-2 -10dBV
3-4 to 1-2 +4dBu
7-8 to 9-10 TS Gain 18dB
1-2 to 9-10 XLR Gain 0dB
1-2 to 9-10 XLR Gain +-20dB

RightMark Audio Analyzer test


Testing chain: External loopback (line-out - line-in)
Sampling mode: 24-bit, 44 kHz




Summary

Test3-4 to 1-2 -10dBV3-4 to 1-2 +4dBu7-8 to 9-10 TS Gain 18dB1-2 to 9-10 XLR Gain 0dB1-2 to 9-10 XLR Gain +-20dB
Frequency response (from 40 Hz to 15 kHz), dB: +0.08, +0.00+0.09, +0.01+0.02, -0.10+0.05, -0.08+0.05, -0.08
Noise level, dB (A): -106.8-111.4-111.2-113.0-96.3
Dynamic range, dB (A): 106.8111.4111.2113.096.4
THD, %: 0.00070.00110.00110.00090.0007
IMD + Noise, %: 0.00500.00500.00510.00500.0064
Stereo crosstalk, dB: -107.1-112.8-111.9-114.4-96.4



Frequency response

Spectrum graph


Noise level

Spectrum graph


Dynamic range

Spectrum graph


THD + Noise (at -3 dB FS)

Spectrum graph


Intermodulation distortion

Spectrum graph


Stereo crosstalk

Spectrum graph



This report was generated by RightMark Audio Analyzer 6.0
